Zigbee dry contact sensor
NODON

Zigbee dry contact sensor

Zigbee connection for dry contact sensors

REFNO-SDC-4-1-01EAN3700313925997
Recommended retail price
49,94 €
incl. 0,04 € eco-fee
Reseller price
Sign in to see your net purchase price excl. VAT

Description

The NodOn dry contact sensor enables connected sensors via Zigbee, allowing them to be integrated into a larger home automation ecosystem.

This makes it possible to monitor and control the sensors remotely. The sensor states can be tracked in real time from a smartphone or a centralized management interface.

Key strengths

Battery-free

The sensor recharges with light to power itself, with an optional battery as backup.

Quick installation

Wireless, mounted with double-sided adhesive or screws.

Responsiveness and automation

Thanks to Zigbee communication, the sensor can interact with other connected devices such as lights or heating systems.

Automatic report

The sensor automatically sends a report of its different states every hour by default, or based on a configurable schedule.

OTA update

The sensor updates quickly thanks to the over-the-air function, via a compatible home automation hub.

Specifications

30m

Range

30g

Weight

2years

Warranty

Compatibility

Works only with a compatible Zigbee home automation hub (remote monitoring and surveillance).

Connectivity & ports

Frequency bandZigbee 2.4 GHz
Radio protocolZigbee 3.0
Zigbee profile0 × 000C : Simple Sensor
Maximum radio power7 dBm/5 mW
Range30 m indoors

Power & battery life

PowerEnergy recovery via photovoltaic cell.
Optional batteryCR2032, 3-year battery life.

Size & weight

Dimensions34 × 85 × 15 mm
Weight30 g

Certifications

Protection ratingIP20
Operating temperature-5 / +45 °C
Commercial warranty2 years

References and weights

BrandNODON
Internal referenceNO-SDC-4-1-01
EAN code3700313925997
Product typeCAPTEURS
Net weight300 g
Gross weight320 g
